285XGR


Some items have Special Edition Morse 100th Anniversary *GOLD* Finish.

Super-Duty Forklift-Karrier. 3-Piece holder secures drum. Pull chain drum tilt control. Requires 25"(63.5 cm) between forks.


285XGR

Specific to model 285XGR...
  • Model 285XGR Drum Holder has heavily reinforced 3-Piece Drum Holder to secure drum
  • Pull chain manual drum tilt control to rotate drum 360o forward and back to pour drum
  • ONLY for a ribbed 55-gallon (210 liter) steel drum
  • Insert Diameter Adapter 55/30-19GR for 30-gallon drum with 18.5" to 19" (47 to 48.3 cm) diameter
All Forklift Attachments to Lift and Pour Drum...
  • SAFETY-CONSCIOUS Forklift Drum Handlers Eliminate DANGEROUS bare fork drum handling
  • Use Morse Forklift-Karriers to Lift, Move and Pour a drum with your forklift
  • Easy to mount forklift drum attachments onto forks
  • Require 25" (63.5 cm) between forks
REQUEST QUOTE CLICK TO CALL

General

Full Capacity

2500 Lb. (1135 kg)

Half-full Capacity1250 Lb. (567.5 kg)

Half-full capacity is an indication of the capacity for an unbalanced, bottom-heavy drum. A partially full drum with an unbalanced and shifting load is harder to tilt than a full drum.

Shipping information

Ship length45" (114.3 cm)
Ship width34" (86.36 cm)
Ship height24" (60.96 cm)
Ship weight270 Lb. (122.58 kg)
Ship class70
sticky note 4-digit serial numbers are simply the month & year of manufacture.
Example: 1120 is November 2020
Click serial range to download.
Operators Manual and Parts Diagram
Serial range

285XGR Super-Duty Forklift-Karrier
Operators Manual
Serial range

Boston Speed Reducers - XGR
Operators Manuals and Parts Diagrams
Serial range

CE Declaration of Conformity - 285
Parts Diagram
Serial range

Chain Wheel Kit

Speed Reducer

Torque Plate Replacement
Click serial range to download.
Recommended Spare Parts Kit
Serial range

RP285-13 Recommended Spare Parts Kit for 285XGR

RP285-13.01 Recommended Spare Parts Kit for 285XGR
55/30-19GR thumbnail image 55/30-19GR

Diameter Adapter for 18.5"-19" (47-48.3 cm) drum. ONLY for 185G, 285G, 185GR, 285GR or 300 Series. Measure diameter 1/2-way down drum.

2838X-P thumbnail image 2838X-P

Fully Enclosed Crate for export of 1 of 285GR Series or model 285XGR. Crate is heat treated and certified IPPC compliant.

X03-285GR thumbnail image X03-285GR

OPTION: Factory Installed 10" diameter hand wheel on NEW model 285A-GR. Replaces pull chain drum tilt control.

2162KIT-P thumbnail image 2162KIT-P

Kit: Safety Chain Anchor for 285 Series. Customer to bolt on or weld to cross tube of Forklift-Karrier.

5026-P thumbnail image 5026-P

KIT, BOLT-ON BRACKET ASSEMBLY FOR 55-GALLON DRUM. TOP CLAMP AND BOTTOM BRACKET. FITS 185XGR, 285XGR OR DISCONTINUED 300 SERIES. 1250LB CAP.

5026L-P

KIT, BOLT-ON BRACKET ASSEMBLY FOR 55-GALLON DRUM. USE IN TANDEM WITH 5026-P. FITS 185XGR, 285XGR OR DISCONTINUED 300 SERIES. 1250LB CAP.
