400A-72SS-115


Some items have Special Edition Morse 100th Anniversary *GOLD* Finish.

Stainless Steel Hydra-Lift Karrier. 72"(183cm) pour. 12V Battery power lift and tilt. Includes battery and charger.Welds NOT ground or polished.


400A-72SS-115

Specific to model 400A-72SS-115...
  • Model 400A-72SS-115 has frame made of bead blast finished type 304 stainless steel
    • Welds are NOT ground smooth or polished
    • Some parts are NOT stainless, such as ratchet, pawl, wheels, motor and hydraulics
    • Gears and sprockets are NOT stainless, but are covered with guards
  • Has 12V battery DC power drum lift and tilt. Includes battery and charger
    • Hold momentary switch and lift valve to raise drum
    • Second valve controls hydraulically-driven drum tilt
    • Manual release valve lowers drum
  • Dispense drum at up to 72" (183 cm) high
  • NOT for use in hazardous areas
All Hydra-Lift Drum Karriers...
  • Hydra-Lift Karriers Lift, Move and Dispense a drum
  • Rotate drum 360 degrees forward and back to dispense into vat, hopper, mixer or other container
  • MORCINCHTM Drum Handling System
    • Drum Holder Automatically adjusts for 22" to 23.5" (56 to 59.7 cm) diameter drum
    • Install correct MORCINCHTM Kit to handle plastic or fiber drum
    • Insert correct size Diameter Adapter for each smaller drum
REQUEST QUOTE CLICK TO CALL

General

Full Capacity

800 Lb. (363.20 kg)

Half-full Capacity 500 Lb. (227.00 kg)

Half-full capacity is an indication of the capacity for an unbalanced, bottom-heavy drum. A partially full drum with an unbalanced and shifting load is harder to tilt than a full drum.

Dispense height 72.0" (182.88 cm)
Lift style Power lift
Tilt style Power tilt

Shipping information

Ship length 67" (170.18 cm)
Ship width 48" (121.92 cm)
Ship height 60" (152.4 cm)
Ship weight 423 Lb. (192.04 kg)
Ship class 150
sticky note 4-digit serial numbers are simply the month & year of manufacture.
Example: 1120 is November 2020
Click serial range to download.
Spec Sheet
Serial range

400SS Series Stainless Steel Hydra-Lift Karriers

Stainless Steel Characteristics
Click serial range to download.
Material Safety data sheet
Serial range

388-P Battery Safety Data Sheet

NOCO Premium Plus Automatic Transmission fluid
Click serial range to download.
Parts Diagram
Serial range

Base Assembly

Hydraulic Lift Cylinder

Hydraulic Motor

Hydraulic Power Pack

MORCINCH Drum Holder

OPTION: Stainless Steel Gears, Power Tilt

Overhead Assembly

Power Lift and Tilt Components

Power Train Components
Operators Manual
Serial range

Battery Charger

Battery Charging Information

Hydra-Lift Karrier
Operators Manual and Parts Diagram
Serial range

Hydraulic Power Pack
2841X-P thumbnail image 2841X-P

Fully enclosed crate for export of 72" 400 Series set up. Crate is heat treated and certified IPPC compliant.

55/30SS-14.5 thumbnail image 55/30SS-14.5

Stainless Steel Adapter for 14-14.5" (35.6-36.8 cm) dia. drum. Brackets for up to 38" (96.5 cm) tall drum. Measure diameter 1/2-way down drum.

55/30SS-16 thumbnail image 55/30SS-16

Stainless Steel Adapter for 15.5-16" (39.4-40.6 cm) dia. drum. Brackets for up to 38" (96.5 cm) tall drum. Measure diameter 1/2-way down drum.

55/30SS-17.5 thumbnail image 55/30SS-17.5

Stainless Steel Adapter for 17-17.5" (43.2-44.5 cm) dia. drum. Brackets for up to 38" (96.5 cm) tall drum. Measure diameter 1/2-way down drum.

55/30SS-19 thumbnail image 55/30SS-19

Stainless Steel Adapter for 18.5" to 19" (47 to 48.3 cm) diameter drum. Measure diameter 1/2-way down drum.

55/30SS-20.5 thumbnail image 55/30SS-20.5

Stainless Steel Adapter for 20" to 20.5" (50.8 to 52.1 cm) diameter drum. Measure diameter 1/2-way down drum.

55/30SS-22 thumbnail image 55/30SS-22

Stainless Steel Adapter for 21.5" to 22" (54.6 to 55.9 cm) diameter drum. Measure diameter 1/2-way down drum.

EB

OPTION: Factory installed SEALED 12V battery on NEW drum handler for export shipment

EC thumbnail image EC

OPTION: Battery Charger for single-phase 240V 50Hz/60Hz power supply with NEW drum handler. Customer must provide correct plug.

GB thumbnail image GB

OPTION: Factory Installed Green Battery on NEW drum handler. Environmentally friendly lithium-ion battery with up to 5 yr. design life.

NB

OPTION: NO Battery on NEW drum handler. End user to install battery before use... Group size 27 12V deep cycle.

NC

OPTION: No Charger. Customer must obtain 12V charger.

PB

OPTION: Factory Installed Premium 12V Battery on NEW drum handler

TB-400SS

OPTION: Factory Installed extra battery and charger on NEW stainless steel 400 series hydra- lift karrier to double duty cycle.

TPB-400SS

OPTION: Factory Installed 2 premium batteries and 2 chargers on stainless steel 400 series karrier to double duty cycle.

55/30SS-19B

Stainless Steel Diameter Adapter for 18.5"-19" Drum. Integrated brackets adjust to 38" tall drum. **Measure outside diameter 1/2-way down drum.

55/30SS-32G thumbnail image 55/30SS-32G

STAINLESS STEEL DIAMETER ADAPTOR FOR 32-GALLON RUBBERMAID BRUTE MODEL 2632

55/30SS-44G thumbnail image 55/30SS-44G

STAINLESS STEEL DIAMETER ADAPTOR FOR 44-GALLON RUBBERMAID BRUTE MODEL 2643

1111i-p

option, factory installed auxiliary valve. Allows metering the lowering of the lift cylinder. Can be closed for postive hold.

4556SS-P thumbnail image 4556SS-P

Kit:Stainless Steel MORCINCH Bracket to prevent RIMLESS or RIMMED plastic drum from slipping. Adjust to 31-39" tall drum. NOT complete drum handler

4560BSS-P thumbnail image 4560BSS-P

KIT: Stainless steel MORCINCH Top Rim Clamp to prevent a RIMMED plastic or fiber drum from slipping. Adjust for RIMMED 30-55 gallon drum.

5115ssi-p thumbnail image 5115ssi-p

OPTION: Factory installed 2" x 3' Web Strap and Stainless Steel Ratchet on NEW MORCINCH Drum Holder. Replaces cinch chain around drum.

5597SSI-P

OPTION: Factory installed stainless steel ratchet and pawl on NEW stainless steel MORCINCH drum holder

6349-P

KIT, SEAL, 6318-P, 6319-P

6388SS-P

STAINLESS STEEL ADAPTOR FOR USE WITH 4556SS-P BRACKET ASSEMBLY IN ORDER TO HANDLE 55 GALLON RUBBERMAID MODEL 2655

6746-P

KIT, SEAL, 1.5" CYL, 783K-P

FGO

OPTION: Factory Installed 1-Gallon of Food Grade Hydraulic Oil

SSG-PT

OPTION: Factory Installed stainless steel tilt gears and roller chain on NEW power tilt 400 or 500 Series

California Proposition 65 Information


...
WARNING: This product can expose you to chemicals including barium sulfate, cobalt, titanium dioxide, and 2-methylimidazole, which are known to the State of California to cause cancer, and bisphenol-A, which is known to the State of California to cause birth defects or other reproductive harm.
...
WARNING: This product can expose you to chemicals including lead and arsenic, which are known to the State of California to cause cancer and birth defects or other reproductive harm.

For more information go to www.P65Warnings.ca.gov
